PORSCHE MACAN TURBO 2.9T (2019 to 2021) - 440HP STAGE 1 PERFORMANCE SOFTWARE TUNE

OVERVIEW

The Porsche Macan Turbo combines Porsche refinement, strong daily drivability, and a highly responsive twin turbocharged V6 platform that benefits greatly from proper ECU calibration. With the 2.9T V6 engine, all wheel drive system, and 7 speed PDK transmission, the Macan Turbo responds extremely well to tuning, especially in throttle response, mid range torque, and overall drivability.

Our AMT performance software is designed to sharpen engine response, improve drivability, and increase usable power throughout the rev range while maintaining smooth and reliable operation. The result is a much more responsive and enjoyable Macan Turbo that feels stronger everywhere without losing the refined character expected from a Porsche SUV.

STAGE 1 CALIBRATION

Stage 1 consists of an individual recalibration of the engine management system, including optimization of key parameters such as ignition, fueling, throttle response, torque control, and related ECU strategies.

This tune is intended for stock or lightly modified vehicles and is developed to improve performance and drivability while remaining within sensible operating limits for the platform.

STAGE 2 CALIBRATION

Stage 2 is intended for vehicles equipped with supporting intake and exhaust modifications that improve airflow. The calibration is adjusted accordingly to take advantage of the hardware changes and deliver stronger overall performance.

KEY FEATURES

• RPM limiter increased
• Top speed governor removal where possible and available in software
• Improved fuel efficiency
• ECU individually reprogrammed
• Optimized responsiveness and drivability
• Optimized for 91 octane / 95 RON fuel
• Test drive with datalog analysis
• Emission standards are maintained
• Improved throttle response
• Datalog analysis

SOFTWARE AVAILABLE

• Stage 1 (89 / 91 Octane)
Requires K&N drop in filter

• Stage 2 (91 / 93 Octane or higher)
Requires cat-back exhaust and cold air intake
Recommended: sports catalysts

GEARBOX / TRANSMISSION TUNE

7 Speed PDK - TCU Tune

Stage 1 - 7 Speed PDK (Temic DL501 Gen2) Transmission Software

Recommended with Stage 1 and Stage 2 ECU tune

• Faster shift speed
• Increased RPM limit matched to ECU tune
• Increased line pressure
• Increased hold pressure
• Increased clutch clamping

Stage 2 - 7 Speed PDK (Temic DL501 Gen2) Transmission Software

Recommended with Stage 2 ECU tune

PERFORMANCE

RECOMMENDED PARTS

Stage 1
K&N drop in filter

Stage 2
Sports catalysts recommended

REQUIRED PARTS FOR STAGE 2

• Cat-back exhaust
• Cold air intake

VEHICLE INFORMATION

Production Date: 2019 to 2021
Engine: 2.9T V6 2997cc
ECU Make: Bosch
ECU Type: MG1CS002
ECU Flashing Method: Direct ECU Connection / OBD at AMT / Bench
TCU Make: Temic
TCU Type: DL501 Gen2
TCU Flashing Method: PWG4 / OBD at AMT
Time Required: 5 to 6 hours

ECU TUNING METHOD

Remote ECU Tuning

For remote ECU tuning, add:

• OBD2 Cable + BBS Flashing Software
Includes 1 year subscription
Requires Windows laptop with internet connection

• Direct ECU Connection Cable
Required for ECU tag: Bosch MG1CS002

This vehicle requires the direct ECU connection cable for remote ECU tuning.

ECU Tuning at AMT

If you do not want to tune remotely, you may:

• Bring the vehicle to AMT Tuning
• Or send the ECU to AMT Tuning for programming

TCU TUNING METHOD

Remote TCU Tuning

For remote TCU tuning, add:

• Powergate 4 Flasher
Transmission only
Required if tuning the TCU remotely

TCU Tuning at AMT

If you do not want to tune remotely, you may:

• Bring the vehicle to AMT Tuning for TCU programming

Please note: the TCU is located inside the transmission and cannot be removed and sent separately to AMT Tuning.

IMPORTANT TOOL INFORMATION

This vehicle requires 2 different tools if tuning both the ECU and TCU remotely:

• ECU Tuning Tool Required: OBD2 Cable + BBS Flashing Software with 1 year subscription plus Direct ECU Connection Cable for ECU tag Bosch MG1CS002
• TCU Tuning Tool Required: Powergate 4 Flasher

FLASHING TOOL OPTIONS

ECU Remote Flashing Tool

OBD2 Cable + BBS Flashing Software (1 Year Subscription Included)
Requires Windows laptop with internet connection

This includes a compatible OBD2 cable with supporting software and 1 year subscription included, allowing you to read and program the vehicle ECU.

ECU Remote Tool Features

• Direct connection to the vehicle through OBD port
• ECU can be restored to factory settings at any time
• Safe to use and user friendly
• Independently able to select and upload your map to your vehicle
• Standard connection to PC via USB port to configure the tools
• Reads possible DTC fault codes and allows them to be erased
• Ability to tune other vehicles with the same tool, with a new tune purchased separately for each vehicle

Direct ECU Connection Cable

2019 to Present - Direct ECU Connection Cable
Required for ECU tag: Bosch MG1CS002

The ECU can only be tuned directly at the ECU, so it requires the direct ECU connection cable for flashing.

TCU Remote Flashing Tool

Powergate 4 Flasher
Transmission only
Required if tuning the TCU remotely

The Powergate 4 works with the Powergate phone app and flashing device, allowing convenient read and write functions for supported transmission applications.

Please note: the Powergate tool does not include the tune itself. The cost of the tool is separate from the software purchase.

ECU SHIPPING OPTION

If you are unable to bring the vehicle to us, the ECU can be removed and shipped to AMT Tuning for programming.

Please make sure the ECU is packed securely and that the package includes a note with the following information:

• Full name
• Order number
• VIN number
• Vehicle year and model
• Contact email
• Contact phone number

This information is required so we can correctly identify the ECU and match it to your order before programming begins.

PACKAGING INSTRUCTIONS

Please pack the ECU securely using anti static material and or bubble wrap.
Ship in a strong padded box with tracking and insurance.

Improper packaging may result in damage during transit.

SHIPPING ADDRESS

AMT Tuning Ltd
6-25 Edilcan Drive
Concord, Ontario L4K 3S4
Canada

Phone: +1 877 469 9440
Email: sales@amttuning.com

IMPORTANT NOTES

• Powergate 4 tool does not include the tune
• Powergate 4 is for TCU tuning only on this application
• Remote ECU tuning requires OBD2 Cable + BBS Flashing Software with 1 year subscription and Direct ECU Connection Cable for ECU tag Bosch MG1CS002
• If tuning both ECU and TCU remotely, 2 different tools are required
• TCU cannot be sent to AMT Tuning because it is located inside the transmission
• ECU can be sent to AMT Tuning for programming
• OBD tuning at AMT Tuning is available for ECU and TCU
• Final gains may vary depending on fuel quality, hardware, ECU software version, and market specification
• Please contact us before ordering if you would like confirmation for your exact vehicle and ECU version
